AD9717BCPZRL7 数据手册
其他文档
AD9714-17 80 pages
AD9717BCPZRL7 48 pages
技术规格
- RoHS: true
- Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
- Datasheet: Analog Devices AD9717BCPZRL7
- Interface: Parallel
- Resolution: 14Bit
- Output Type: Current-非缓冲
- Supply Voltage: 1.7V~1.9V
- Integral nonlinearity: ±1.8LSB;±1.7LSB
- Operating Temperature: -40°C~+85°C
- Package: LFCSP-40
- Manufacturer: Analog Devices
- Series: TxDAC®
- Packaging: Cut Tape (CT)
- Part Status: Active
- Number of Bits: 14
- Number of D/A Converters: 2
- Settling Time: -
- Differential Output: Yes
- Data Interface: Parallel
- Reference Type: External, Internal
- Voltage - Supply, Analog: 1.7V ~ 3.5V
- Voltage - Supply, Digital: 1.7V ~ 1.9V
- INL/DNL (LSB): ±1.8, ±1.7
- Architecture: Current Source
- Package / Case: 40-VFQFN Exposed Pad, CSP
- Supplier Device Package: 40-LFCSP-VQ (6x6)
- Mounting Type: Surface Mount
- Base Part Number: AD9717
- detail: 14 Bit Digital to Analog Converter 2 40-LFCSP-VQ (6x6)
