TL750M05QKVURQ1 دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت TL750M05QKVURQ1	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Linear Voltage Regulators (LDO)
Datasheet: Texas Instruments TL750M08QKVURQ1
Output Current: 750mA
Output Voltage: 8V
Dropout Voltage: 0.6V@(750mA)
Output Polarity: positive
Number of Outputs: 1
Maximum Input Voltage: 26V
Operating Temperature: -40°C~+125°C
Power Supply Rejection Ratio (PSRR): 55dB@(120Hz)
Package: TO-252
Manufacturer: Texas Instruments
Series: Automotive, AEC-Q100
Voltage Dropout (Max): 0.6V @ 750mA
Package / Case: TO-252-3, DPak (2 Leads + Tab), SC-63
Base Part Number: TL750
Supplier Device Package: TO-252-3
Current - Output: 750mA
PSRR: 55dB (120Hz)
Part Status: Active
Voltage - Input (Max): 26V
Mounting Type: Surface Mount
Control Features: -
Protection Features: Over Current, Over Temperature, Over Voltage, Reverse Polarity
Voltage - Output (Min/Fixed): 8V
Voltage - Output (Max): -
Packaging: Cut Tape (CT)
Output Configuration: Positive
Number of Regulators: 1
Output Type: Fixed
detail: Linear Voltage Regulator IC 1 Output 750mA TO-252-3
