AD7243ANZ دیتاشیت

AD7243ANZ

مشخصات دیتاشیت

نام دیتاشیت AD7243ANZ
حجم فایل 99.249 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

مشاهده دیتاشیت AD7243ANZ

دانلود دیتاشیت

سایر مستندات

AD7243 13 pages

مشخصات فنی

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Digital To Analog Converters (DACs)
  • Datasheet: Analog Devices AD7243ANZ
  • Interface: SPI
  • Resolution: 12Bit
  • Output Type: Voltage-缓冲
  • Settling Time: 10us
  • Integral nonlinearity: ±1LSB;±0.9LSB
  • Operating Temperature: -40°C~+85°C
  • Package: PDIP-16
  • Manufacturer: Analog Devices
  • Series: DACPORT®
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 1
  • Differential Output: No
  • Data Interface: SPI
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: ±10.8V ~ 16.5V
  • Voltage - Supply, Digital: -
  • INL/DNL (LSB): ±1 (Max), ±0.9 (Max)
  • Architecture: R-2R
  • Package / Case: 16-DIP (0.300", 7.62mm)
  • Supplier Device Package: 16-PDIP
  • Mounting Type: Through Hole
  • Base Part Number: AD7243
  • detail: 12 Bit Digital to Analog Converter 1 16-PDIP
