دیتاشیت ADG528ATQ
مشخصات دیتاشیت
| نام دیتاشیت |
ADG528ATQ
|
| حجم فایل |
80.099
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
13
|
مشخصات فنی
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices ADG528ATQ
-
Turn-on time:
300ns
-
Turn-off time:
300ns
-
Supply Voltage:
10.8V~16.5V
-
Number of Channels:
1
-
On-State Resistance (Max):
450Ω
-
Package:
DIP-18
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Switch Circuit:
-
-
Multiplexer/Demultiplexer Circuit:
8:1
-
Number of Circuits:
1
-
Channel-to-Channel Matching (ΔRon):
22.5Ohm
-
Voltage - Supply, Single (V+):
10.8V ~ 16.5V
-
Voltage - Supply, Dual (V±):
±10.8V ~ 16.5V
-
Switch Time (Ton, Toff) (Max):
300ns, 300ns
-
-3db Bandwidth:
-
-
Charge Injection:
4pC
-
Channel Capacitance (CS(off), CD(off)):
5pF, 22pF
-
Current - Leakage (IS(off)) (Max):
1nA
-
Crosstalk:
-
-
Operating Temperature:
-55°C ~ 125°C (TA)
-
Mounting Type:
Through Hole
-
Package / Case:
18-CDIP (0.300", 7.62mm)
-
Supplier Device Package:
18-CDIP
-
Base Part Number:
ADG528
-
detail:
1 Circuit IC Switch 8:1 450Ohm 18-CDIP
