- دیتاشیت PIC18LF252-I/SP
PIC18LF252-I/SP دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | PIC18LF252-I/SP |
|---|---|
| حجم فایل | 30.156 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 332 |
دانلود دیتاشیت PIC18LF252-I/SP |
دانلود دیتاشیت |
|---|
سایر مستندات
Timer1 Errata 8 pages
PIC18Fxx2, xx8 Programming Specification 36 pages
PIC18Fxx2 Datasheet 332 pages
PIC18Fxx2 Rev.B2 Datasheet Errata 16 pages
PIC18Fxx2 Rev C0 Errata 16 pages
PIC18F2x2, 4x2 Rev B5 Errata 14 pages
مشخصات فنی
- RoHS: true
- EEPROM: 256Byte
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 1.5KB
- Watchdog: Yes
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: Microchip Tech PIC18LF252-I/SP
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 40MHz
- GPIO Ports Number: 23
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: -
- Peripheral/Function: PWM
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 32KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 2V~5.5V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: SPDIP-28
- Manufacturer: Microchip Tech
- Series: PIC® 18F
- Packaging: Tube
- Part Status: Active
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 40MHz
- Connectivity: I²C, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, LVD, POR, PWM, WDT
- Number of I/O: 23
- Program Memory Size: 32KB (16K x 16)
- EEPROM Size: 256 x 8
- Voltage - Supply (Vcc/Vdd): 2V ~ 5.5V
- Data Converters: A/D 5x10b
- Oscillator Type: External
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Through Hole
- Package / Case: 28-DIP (0.300", 7.62mm)
- Supplier Device Package: 28-SPDIP
- Base Part Number: PIC18LF252
- detail: PIC PIC® 18F Microcontroller IC 8-Bit 40MHz 32KB (16K x 16) FLASH 28-SPDIP
