SN74LV374ATPWREP دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت SN74LV374ATPWREP	دانلود دیتاشیت

RoHS: true
Type: D-Type
Series: 74LV
Category: Logic ICs/Flip Flops
Function: -
Datasheet: Texas Instruments SN74LV374ATPWREP
Output Type: Tri-State;Non-Inverted
Sink Current: 16mA
Trigger Type: 上升沿
Source Current: 16mA
Supply Voltage: 2V~5.5V
Clock Frequency: 170MHz
Input Capacitance: 2.9pF
Number of Elements: 1
Operating Temperature: -40°C~+105°C
Quiescent Current (Iq): 20uA
Maximum Propagation Delay: 10.1ns@5V,50pF
Number of Bits per Element: 8
Package: TSSOP-20
Manufacturer: Texas Instruments
Package / Case: 20-TSSOP (0.173", 4.40mm Width)
Current - Output High, Low: 16mA, 16mA
Current - Quiescent (Iq): 20µA
Part Status: Active
Mounting Type: Surface Mount
Max Propagation Delay @ V, Max CL: 10.1ns @ 5V, 50pF
Voltage - Supply: 2V ~ 5.5V
Packaging: Cut Tape (CT)
Base Part Number: SN74LV37
Supplier Device Package: 20-TSSOP
detail: Flip Flop 1 Element D-Type 8 Bit Positive Edge 20-TSSOP (0.173", 4.40mm Width)
