دیتاشیت ADG1222BRMZ-REEL7

مشخصات دیتاشیت

دانلود دیتاشیت ADG1221-23	ADG1221-23 Datasheet

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices ADG1222BRMZ-REEL7
Turn-on time: 130ns
Turn-off time: 105ns
Supply Voltage: 5V~16.5V
Switch Circuit: SPST(SPST)-Normally closed
Number of Channels: 2
On-State Resistance (Max): 200Ω
Package: MSOP-10
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Multiplexer/Demultiplexer Circuit: 1:1
Number of Circuits: 2
Channel-to-Channel Matching (ΔRon): 2.5Ohm
Voltage - Supply, Single (V+): 5V ~ 16.5V
Voltage - Supply, Dual (V±): ±5V ~ 16.5V
Switch Time (Ton, Toff) (Max): 130ns, 105ns
-3db Bandwidth: 960MHz
Charge Injection: 0.1pC
Channel Capacitance (CS(off), CD(off)): 2.2pF, 2.2pF
Current - Leakage (IS(off)) (Max): 100pA
Crosstalk: -90dB @ 1MHz
Operating Temperature: -40°C ~ 125°C (TA)
Mounting Type: Surface Mount
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
Supplier Device Package: 10-MSOP
Base Part Number: ADG1222
detail: 2 Circuit IC Switch 1:1 200Ohm 10-MSOP
