دیتاشیت ADP5073ACPZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP5073
|
| حجم فایل |
514.324
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
17
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Function:
Ratiometric, Step-Up/Step-Down
-
Output Configuration:
Negative
-
Topology:
Buck-Boost
-
Output Type:
Adjustable
-
Number of Outputs:
1
-
Voltage - Input (Min):
2.85V
-
Voltage - Input (Max):
15V
-
Voltage - Output (Min/Fixed):
Vin-39V
-
Voltage - Output (Max):
-
-
Current - Output:
1.2A
-
Frequency - Switching:
1.2MHz, 2.4MHz
-
Synchronous Rectifier:
No
-
Operating Temperature:
-40°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
16-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
16-LFCSP-WQ (3x3)
-
Base Part Number:
ADP5073
-
detail:
Buck-Boost Switching Regulator IC Negative Adjustable Vin-39V 1 Output 1.2A 16-WFQFN Exposed Pad, CSP
