ADUM7241CRZ دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت ADUM7241CRZ	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Digital Isolators
Data Rate: 25Mbps
Datasheet: Analog Devices ADUM7241CRZ
Applications: General-purpose
Supply Voltage: 3V~5.5V
Forward Channel: 1
Reverse channel: 1
Number of Channels: 2
Isolation Technology: Magnetic isolation
Operating Temperature: -40°C~+105°C
Voltage Isolation or Not: Without voltage isolation
Package: SOIC-8
Manufacturer: Analog Devices
Series: iCoupler®
Packaging: Tube
Part Status: Active
Technology: Magnetic Coupling
Type: General Purpose
Isolated Power: No
Inputs - Side 1/Side 2: 1/1
Channel Type: Unidirectional
Voltage - Isolation: 1000Vrms
Common Mode Transient Immunity (Min): 15kV/µs
Propagation Delay tpLH / tpHL (Max): 50ns, 50ns
Pulse Width Distortion (Max): 5ns
Rise / Fall Time (Typ): 2ns, 2ns
Voltage - Supply: 3V ~ 5.5V
Mounting Type: Surface Mount
Package / Case: 8-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 8-SOIC
Base Part Number: ADUM7241
detail: General Purpose Digital Isolator 1000Vrms 2 Channel 25Mbps 15kV/µs CMTI 8-SOIC (0.154", 3.90mm Width)
