TPS2211A Datasheet دیتاشیت

TPS2211A Datasheet

مشخصات دیتاشیت

نام دیتاشیت TPS2211A Datasheet
حجم فایل 1147.042 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

مشاهده دیتاشیت TPS2211A Datasheet

دانلود دیتاشیت

سایر مستندات

TPS2211AIDBR 33 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Power Distribution Switches
  • Datasheet: Texas Instruments TPS2211APWR
  • Input Voltage: 3.3V;5V;12V
  • Output Current: 1A
  • Number of Outputs: 2
  • Resistor On-State: 70mΩ
  • Operating Temperature -: -40°C~+85°C
  • Package: TSSOP-20
  • Manufacturer: Texas Instruments
  • Voltage - Supply (Vcc/Vdd): Not Required
  • Base Part Number: TPS221
  • Operating Temperature: -40°C ~ 85°C (TA)
  • Package / Case: 20-PowerTSSOP (0.173", 4.40mm Width)
  • Ratio - Input:Output: 3:2
  • Current - Output (Max): 1A
  • Voltage - Load: 3.3V, 5V, 12V
  • Series: -
  • Rds On (Typ): 70mOhm
  • Supplier Device Package: 20-HTSSOP
  • Fault Protection: Current Limiting (Fixed), Over Temperature
  • Output Configuration: High Side
  • Part Status: Active
  • Mounting Type: Surface Mount
  • Interface: Parallel
  • Switch Type: PCMCIA Switch
  • Packaging: Tape & Reel (TR)
  • Input Type: -
  • Features: Status Flag
  • Output Type: -
  • detail: Power Switch/Driver 3:2 1A 20-HTSSOP
