دیتاشیت ADUM241E0BRWZ
مشخصات دیتاشیت
| نام دیتاشیت |
ADuM240-42D/E
|
| حجم فایل |
477.045
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
26
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
iCoupler®
-
Packaging:
Tube
-
Part Status:
Active
-
Technology:
Magnetic Coupling
-
Type:
General Purpose
-
Isolated Power:
No
-
Number of Channels:
4
-
Inputs - Side 1/Side 2:
3/1
-
Channel Type:
Unidirectional
-
Voltage - Isolation:
5000Vrms
-
Common Mode Transient Immunity (Min):
75kV/µs
-
Data Rate:
150Mbps
-
Propagation Delay tpLH / tpHL (Max):
13ns, 13ns
-
Pulse Width Distortion (Max):
3ns
-
Rise / Fall Time (Typ):
2.5ns, 2.5ns
-
Voltage - Supply:
1.7V ~ 5.5V
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
16-SOIC (0.295", 7.50mm Width)
-
Supplier Device Package:
16-SOIC
-
Base Part Number:
ADUM241
-
detail:
General Purpose Digital Isolator 5000Vrms 4 Channel 150Mbps 75kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
