ADUM4070ARIZ دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADUM4070ARIZ
|
|
حجم فایل
|
88.941
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
20
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Buck-boost type
-
Topology:
Push-pull
-
Datasheet:
Analog Devices ADUM4070ARIZ
-
Output Type:
Adjustable
-
Input Voltage:
3V~7V
-
Output Voltage:
3.3V~24V
-
Number of Outputs:
1
-
Switching Frequency:
1MHz
-
Output Current (Max):
350mA
-
Operating Temperature:
-40°C~+105°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
SOP-16-300mil
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive, Isolation Capable
-
Voltage - Input (Min):
3V
-
Voltage - Input (Max):
7V
-
Voltage - Output (Min/Fixed):
3.3V
-
Voltage - Output (Max):
24V
-
Current - Output:
350mA
-
Frequency - Switching:
200kHz ~ 1MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
16-SOIC (0.295", 7.50mm Width)
-
Supplier Device Package:
16-SOIC-IC
-
Base Part Number:
ADUM4070
-
detail:
Push-Pull Switching Regulator IC Positive, Isolation Capable Adjustable 3.3V 1 Output 350mA 16-SOIC (0.295", 7.50mm Width)
