دیتاشیت ADM7151ACPZ-04-R7

ADM7151

مشخصات دیتاشیت

نام دیتاشیت ADM7151
حجم فایل 1169.758 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت ADM7151

ADM7151 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 16V
  • Voltage - Output (Min/Fixed): 1.5V
  • Voltage - Output (Max): 5.1V
  • Voltage Dropout (Max): 1.2V @ 800mA
  • Current - Output: 800mA
  • Current - Quiescent (Iq): 7mA
  • Current - Supply (Max): 12mA
  • PSRR: 94dB ~ 53dB (1kHz ~ 1MHz)
  • Control Features: Enable
  • Protection Features: Over Temperature, Short Circuit
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-WFDFN Exposed Pad, CSP
  • Supplier Device Package: 8-LFCSP-WD (3x3)
  • Base Part Number: ADM7151
  • detail: Linear Voltage Regulator IC 1 Output 800mA 8-LFCSP-WD (3x3)
