CSD87351ZQ5D دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت CSD87351ZQ5D	دانلود دیتاشیت

RoHS: true
Type: 2PCSNChannel(不对称)
Category: Triode/MOS Tube/Transistor/MOSFETs
Datasheet: Texas Instruments CSD87351ZQ5D
Operating Temperature: -55°C~+150°C@(Tj)
Power Dissipation (Pd): 12W
Total Gate Charge (Qg@Vgs): 7.7nC@4.5V
Drain Source Voltage (Vdss): 30V
Input Capacitance (Ciss@Vds): 1255pF@15V
Continuous Drain Current (Id): 32A
Gate Threshold Voltage (Vgs(th)@Id): 2.1V@250uA
Package: LSON-CLIP-8
Manufacturer: Texas Instruments
Series: NexFET™
Current - Continuous Drain (Id) @ 25°C: 32A
Rds On (Max) @ Id, Vgs: -
Power - Max: 12W
Supplier Device Package: 8-LSON (5x6)
Package / Case: 8-PowerLDFN
Gate Charge (Qg) (Max) @ Vgs: 7.7nC @ 4.5V
FET Feature: Logic Level Gate
Part Status: Discontinued at Digi-Key
Mounting Type: Surface Mount
Input Capacitance (Ciss) (Max) @ Vds: 1255pF @ 15V
Drain to Source Voltage (Vdss): 30V
Vgs(th) (Max) @ Id: 2.1V @ 250µA
Packaging: Cut Tape (CT)
Base Part Number: CSD87351
FET Type: 2 N-Channel (Dual) Asymmetrical
detail: Mosfet Array 2 N-Channel (Dual) Asymmetrical 30V 32A 12W Surface Mount 8-LSON (5x6)
