دیتاشیت ADP3301ARZ-3.3
مشخصات دیتاشیت
| نام دیتاشیت |
ADP3301
|
| حجم فایل |
411.945
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Analog Devices ADP3301ARZ-3.3
-
Output Type:
Fixed
-
Output Current:
100mA
-
Output Voltage:
3.3V
-
Dropout Voltage:
200mV@(100mA)
-
Output Polarity:
Positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
12V
-
Operating Temperature:
-20°C~+85°C@(Ta)
-
Quiescent Current (Ground Current):
300uA
-
Power Supply Rejection Ratio (PSRR):
-
-
Package:
SOIC-8
-
Manufacturer:
Analog Devices
-
Series:
anyCAP®
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
12V
-
Voltage - Output (Min/Fixed):
3V
-
Voltage - Output (Max):
-
-
Voltage Dropout (Max):
0.2V @ 100mA
-
Current - Output:
100mA
-
Current - Quiescent (Iq):
300µA
-
Current - Supply (Max):
2mA
-
PSRR:
-
-
Control Features:
Enable
-
Protection Features:
Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
ADP3301
-
detail:
Linear Voltage Regulator IC 1 Output 100mA 8-SOIC
