APT75GN120JDQ3 دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت APT75GN120JDQ3	دانلود دیتاشیت

Manufacturer: Microchip Technology
Series: -
Packaging: Tube
Part Status: Active
IGBT Type: Trench Field Stop
Configuration: Single
Voltage - Collector Emitter Breakdown (Max): 1200V
Current - Collector (Ic) (Max): 124A
Power - Max: 379W
Vce(on) (Max) @ Vge, Ic: 2.1V @ 15V, 75A
Current - Collector Cutoff (Max): 200µA
Input Capacitance (Cies) @ Vce: 4.8nF @ 25V
Input: Standard
NTC Thermistor: No
Operating Temperature: -55°C ~ 150°C (TJ)
Mounting Type: Chassis Mount
Package / Case: ISOTOP
Supplier Device Package: ISOTOP®
detail: IGBT Module Trench Field Stop Single 1200V 124A 379W Chassis Mount ISOTOP®
