TPS72718YFFT Datasheet
Datasheet specifications
| Datasheet's name | TPS72718YFFT |
|---|---|
| File size | 729.056 KB |
| File type | |
| Number of pages | 22 |
Download Datasheet TPS72718YFFT |
Download Datasheet |
|---|
Other documentations
TPS727xx 36 pages
TPS72730DSET 35 pages
Technical specifications
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Texas Instruments TPS72718YFFT
- Output Current: 250mA
- Output Voltage: 1.8V
- Dropout Voltage: 0.2V@(200mA)
- Output Polarity: positive
- Number of Outputs: 1
- Maximum Input Voltage: 5.5V
- Operating Temperature: -40°C~+125°C
- Quiescent Current (Ground Current): 110uA
- Package: BGA-4
- Manufacturer: Texas Instruments
- Voltage Dropout (Max): 0.2V @ 200mA
- Current - Supply (Max): 130µA
- Current - Output: 250mA
- Current - Quiescent (Iq): 110µA
- Voltage - Input (Max): 5.5V
- Base Part Number: TPS727
- Package / Case: 4-UFBGA, DSBGA
- Voltage - Output (Max): -
- Output Configuration: Positive
- Series: -
- Supplier Device Package: 4-DSBGA (1x1)
- PSRR: 85dB ~ 45dB (10Hz ~ 1MHz)
- Part Status: Active
- Mounting Type: Surface Mount
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Under Voltage Lockout (UVLO)
- Voltage - Output (Min/Fixed): 1.8V
- Number of Regulators: 1
- Packaging: Cut Tape (CT)
- Output Type: Fixed
- detail: Linear Voltage Regulator IC 1 Output 250mA 4-DSBGA (1x1)
