MIC5323YMT-TR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
MIC5323YMT-TR
|
|
حجم فایل
|
95.475
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
15
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Microchip Tech MIC5323YMT-TR
-
Output Type:
Adjustable
-
Output Current:
300mA
-
Output Voltage:
1.25V~5.5V
-
Dropout Voltage:
0.17V@(300mA)
-
Output Polarity:
positive
-
Number of Outputs:
1
-
Maximum Input Voltage:
5.5V
-
Operating Temperature:
-40°C~+125°C
-
Quiescent Current (Ground Current):
150uA
-
Package:
MLF-6
-
Manufacturer:
Microchip Tech
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Number of Regulators:
1
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
1.25V
-
Voltage - Output (Max):
5.5V
-
Voltage Dropout (Max):
0.17V @ 300mA
-
Current - Output:
300mA
-
Current - Quiescent (Iq):
150µA
-
PSRR:
80dB ~ 65dB (1kHz ~ 10kHz)
-
Control Features:
Enable
-
Protection Features:
Over Current, Over Temperature
-
Mounting Type:
Surface Mount
-
Package / Case:
6-UDFN Exposed Pad, 6-TMLF®
-
Supplier Device Package:
6-TMLF® (2x2)
-
Base Part Number:
MIC5323
-
detail:
Linear Voltage Regulator IC 1 Output 300mA 6-TMLF® (2x2)
