ADGS1212BCPZ دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADGS1212 Datasheet
|
|
حجم فایل
|
654.586
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
24
|
مشخصات فنی
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Tray
-
Part Status:
Active
-
Switch Circuit:
SPST - NO
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Number of Circuits:
4
-
On-State Resistance (Max):
260Ohm, 625Ohm
-
Channel-to-Channel Matching (ΔRon):
11Ohm, 27Ohm
-
Voltage - Supply, Single (V+):
5V ~ 16.5V
-
Voltage - Supply, Dual (V±):
±4.5V ~ 16.5V
-
Switch Time (Ton, Toff) (Max):
490ns, 225ns
-
-3db Bandwidth:
1GHz
-
Charge Injection:
1pC
-
Channel Capacitance (CS(off), CD(off)):
1.4pF, 1.5pF
-
Current - Leakage (IS(off)) (Max):
1nA
-
Crosstalk:
-110dB @ 1MHz
-
Operating Temperature:
-40°C ~ 125°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
24-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
24-LFCSP-WQ (4x4)
-
Base Part Number:
ADGS1212
-
detail:
4 Circuit IC Switch 1:1 260Ohm, 625Ohm 24-LFCSP-WQ (4x4)
