REF02HPZ 数据手册
其他文档
REF01,02,03 20 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Analog Devices REF02HPZ
- Tolerance: ±0.5%
- Output Type: Fixed
- Input Voltage: 7V~36V
- Output Current: 10mA
- Output Voltage: 5V
- Reference Type: series connection
- Supply Current: 1.4mA
- Noise - 10Hz to 10kHz: -
- Operating Temperature: -40°C~+85°C@(Ta)
- Noise - 1/10Hz to 10Hz: 15uVp-p
- Temperature Coefficient: 25ppm/°C
- Package: PDIP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Voltage - Output (Min/Fixed): 5V
- Current - Output: 10mA
- Noise - 0.1Hz to 10Hz: 15µVp-p
- Voltage - Input: 7V ~ 40V
- Current - Supply: 1.4mA
- Mounting Type: Through Hole
- Package / Case: 8-DIP (0.300", 7.62mm)
- Supplier Device Package: 8-PDIP
- Base Part Number: REF02
- detail: Series Voltage Reference IC ±0.5% 8-PDIP
