SN74LV123ATPWREP دیتاشیت

SN74LV123ATPWREP

مشخصات دیتاشیت

نام دیتاشیت SN74LV123ATPWREP
حجم فایل 112.687 کیلوبایت
نوع فایل pdf
تعداد صفحات 13

دانلود دیتاشیت SN74LV123ATPWREP

دانلود دیتاشیت

سایر مستندات

Logic Guide 20 pages

SN74LV123A-EP 13 pages

مشخصات فنی

  • RoHS: true
  • Category: Logic ICs/Monostable Multivibrators
  • Datasheet: Texas Instruments SN74LV123ATPWREP
  • Input Type: Schmitt Trigger
  • Logic Family: 74LV
  • Sink Current: 12mA
  • Source Current: 12mA
  • Supply Voltage: 2V~5.5V
  • Logic Gate Type: Monostable
  • Propagation Delay: 10.5ns
  • Number Of Channels: 2
  • OperatingTemperature: -40°C~+105°C
  • Package: TSSOP-16
  • Manufacturer: Texas Instruments
  • Series: 74LV
  • Package / Case: 16-TSSOP (0.173", 4.40mm Width)
  • Supplier Device Package: 16-TSSOP
  • Part Status: Active
  • Current - Output High, Low: 12mA, 12mA
  • Mounting Type: Surface Mount
  • Schmitt Trigger Input: Yes
  • Operating Temperature: -40°C ~ 105°C
  • Independent Circuits: 2
  • Voltage - Supply: 2V ~ 5.5V
  • Packaging: Cut Tape (CT)
  • Base Part Number: SN74LV12
  • Logic Type: Monostable
  • detail: Monostable Multivibrator 10.5ns 16-TSSOP
