TPS61177RGRR دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | TPS61177RGRR |
|---|---|
| حجم فایل | 15.758 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 10 |
دانلود دیتاشیت TPS61177RGRR |
دانلود دیتاشیت |
|---|
سایر مستندات
TPS61177RGRR Packaging 8 pages
مشخصات فنی
- RoHS: true
- Type: DC-DCVoltage Stabilizer
- Dimming: Analog;PWM
- Category: Nixie Tube Driver/LED Driver/LED Drivers
- Channels: 6
- Topology: boost converter
- Datasheet: Texas Instruments TPS61177RGRR
- Input Voltage: 2.5V~24V
- Output Current: 30mA
- Output Voltage: 39V
- Switch Frequency: 1.25MHz
- Operating temperature: -40°C~+85°C
- Package: VQFN-20(3.5x3.5)
- Manufacturer: Texas Instruments
- Series: -
- Package / Case: 20-VFQFN Exposed Pad
- Frequency: 1.25MHz
- Number of Outputs: 6
- Part Status: Discontinued at Digi-Key
- Mounting Type: Surface Mount
- Internal Switch(s): Yes
- Applications: Backlight
- Voltage - Supply (Min): 2.5V
- Current - Output / Channel: 30mA
- Voltage - Output: 39V
- Packaging: Cut Tape (CT)
- Base Part Number: TPS611
- Supplier Device Package: 20-VQFN (3.5x3.5)
- Voltage - Supply (Max): 24V
- detail: LED Driver IC 6 Output DC DC Regulator Step-Up (Boost) Analog, PWM Dimming 30mA 20-VQFN (3.5x3.5)
