LP8552 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LP8552
|
|
حجم فایل
|
1572.312
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
49
|
مشخصات فنی
-
RoHS:
true
-
Type:
DC-DCVoltage Stabilizer
-
Dimming:
PWM
-
Category:
Nixie Tube Driver/LED Driver/LED Drivers
-
Channels:
6
-
Topology:
boost converter
-
Datasheet:
Texas Instruments LP8552TLX-E06/NOPB
-
Input Voltage:
2.7V~22V
-
Output Current:
450mA
-
Output Voltage:
40V
-
Operating temperature:
-40°C~+85°C
-
Package:
BGA-25
-
Manufacturer:
Texas Instruments
-
Series:
-
-
Package / Case:
25-WFBGA, DSBGA
-
Frequency:
-
-
Number of Outputs:
6
-
Part Status:
Active
-
Mounting Type:
Surface Mount
-
Internal Switch(s):
Yes
-
Applications:
Backlight
-
Voltage - Supply (Min):
2.7V
-
Current - Output / Channel:
450mA
-
Voltage - Output:
40V
-
Packaging:
Cut Tape (CT)
-
Base Part Number:
LP8552
-
Supplier Device Package:
25-DSBGA (2.46x2.46)
-
Voltage - Supply (Max):
22V
-
detail:
LED Driver IC 6 Output DC DC Regulator Step-Up (Boost) PWM Dimming 450mA 25-DSBGA (2.46x2.46)
