MIC4103YM دیتاشیت

MIC4103YM

مشخصات دیتاشیت

نام دیتاشیت MIC4103YM
حجم فایل 93.295 کیلوبایت
نوع فایل pdf
تعداد صفحات 19

مشاهده دیتاشیت MIC4103YM

دانلود دیتاشیت

سایر مستندات

MIC4103,04 19 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Gate Drive ICs
  • Datasheet: Microchip Tech MIC4103YM
  • Fall Time: 6ns
  • Load Type: MOSFET
  • Rise Time: 10ns
  • Supply Voltage: 9V~16V
  • Number of Drivers: 2
  • Driven Configuration: Half Bridge
  • Operating Temperature: -40°C~+125°C@(Tj)
  • Peak Output Current(sink): 3A
  • Peak Output Current(source): 2A
  • Package: SOP-8
  • Manufacturer: Microchip Tech
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Channel Type: Independent
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 9V ~ 16V
  • Logic Voltage - VIL, VIH: 3V, 8V
  • Current - Peak Output (Source, Sink): 2A, 3A
  • Input Type: Non-Inverting
  • High Side Voltage - Max (Bootstrap): 118V
  • Rise / Fall Time (Typ): 10ns, 6ns
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: MIC4103
  • detail: Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
