UCC25706QDRQ1 دیتاشیت

UCC25706QDRQ1

مشخصات دیتاشیت

نام دیتاشیت UCC25706QDRQ1
حجم فایل 74.019 کیلوبایت
نوع فایل pdf
تعداد صفحات 17

مشاهده دیتاشیت UCC25706QDRQ1

دانلود دیتاشیت

سایر مستندات

UCC2570(5,6)-Q1 18 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/AC-DC Controllers & Regulators
  • Topology: Boost;Flyback;Forward
  • Datasheet: Texas Instruments UCC25706QDRQ1
  • Duty Cycle: 93%
  • Supply Voltage: 8V~15V
  • Output Isolation: Isolation
  • Switching Frequency: 1MHz
  • Operating Temperature: -55°C~+150°C@(Tj)
  • Package: SOP-8
  • Manufacturer: Texas Instruments
  • Series: Automotive, AEC-Q100
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Frequency - Switching: 1MHz
  • Voltage - Supply (Vcc/Vdd): 8V ~ 15V
  • Part Status: Discontinued at Digi-Key
  • Fault Protection: Current Limiting
  • Voltage - Breakdown: -
  • Control Features: -
  • Internal Switch(s): No
  • Voltage - Start Up: 12V
  • Mounting Type: Surface Mount
  • Packaging: Cut Tape (CT)
  • Base Part Number: UCC257
  • detail: Converter Offline Boost, Flyback, Forward Topology 1MHz 8-SOIC
