- دیتاشیت MIC4100YM
MIC4100YM دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | MIC4100YM |
|---|---|
| حجم فایل | 76.704 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت MIC4100YM |
دانلود دیتاشیت |
|---|
سایر مستندات
MIC4100, MIC4101 18 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/Gate Drive ICs
- Datasheet: Microchip Tech MIC4100YM
- Fall Time: 400ns
- Load Type: MOSFET
- Rise Time: 400ns
- Supply Voltage: 9V~16V
- Number of Drivers: 2
- Driven Configuration: Half Bridge
- Operating Temperature: -40°C~+125°C@(Tj)
- Peak Output Current(sink): 2A
- Peak Output Current(source): 2A
- Package: SOP-8
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Channel Type: Independent
- Gate Type: N-Channel MOSFET
- Voltage - Supply: 9V ~ 16V
- Logic Voltage - VIL, VIH: 3V, 8V
- Current - Peak Output (Source, Sink): 2A, 2A
- Input Type: Non-Inverting
- High Side Voltage - Max (Bootstrap): 118V
- Rise / Fall Time (Typ): 400ns, 400ns
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: MIC4100
- detail: Half-Bridge Gate Driver IC Non-Inverting 8-SOIC
