دیتاشیت ADP5022ACBZ-2-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP5022
|
| حجم فایل |
1096.855
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
28
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/Linear Voltage Regulators (LDO)
-
Datasheet:
Analog Devices ADP5022ACBZ-2-R7
-
Operating Temperature:
-40°C~+125°C
-
Package:
WLCSP-16(2.1x2.1)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
Topology:
Step-Down (Buck) Synchronous (2), Linear (LDO) (1)
-
Number of Outputs:
3
-
Frequency - Switching:
3MHz
-
Voltage/Current - Output 1:
1.2V, 600mA
-
Voltage/Current - Output 2:
1.8V, 600mA
-
Voltage/Current - Output 3:
2.8V, 150mA
-
w/LED Driver:
No
-
w/Supervisor:
No
-
w/Sequencer:
No
-
Voltage - Supply:
2.3V ~ 5.5V
-
Mounting Type:
Surface Mount
-
Package / Case:
16-WFBGA, WLCSP
-
Supplier Device Package:
16-WLCSP (2.08x2.08)
-
Base Part Number:
ADP5022
-
detail:
PMIC - Voltage Regulators - Linear + Switching 3 Output Step-Down (Buck) Synchronous (2), Linear (LDO) (1) 3MHz 16-WLCSP (2.08x2.08)
