دیتاشیت ADG621BRMZ-REEL
مشخصات دیتاشیت
| نام دیتاشیت |
ADG621
|
| حجم فایل |
241.552
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
12
|
مشخصات
-
RoHS:
true
-
Category:
Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
-
Datasheet:
Analog Devices ADG621BRMZ-REEL
-
Turn-on time:
120ns
-
Turn-off time:
70ns
-
Supply Voltage:
2.7V~5.5V
-
Switch Circuit:
SPST(SPST)-Normal Open
-
Number of Channels:
2
-
On-State Resistance (Max):
5.5Ω
-
Package:
MSOP-10
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Multiplexer/Demultiplexer Circuit:
1:1
-
Number of Circuits:
2
-
Channel-to-Channel Matching (ΔRon):
250mOhm
-
Voltage - Supply, Single (V+):
2.7V ~ 5.5V
-
Voltage - Supply, Dual (V±):
±2.7V ~ 5.5V
-
Switch Time (Ton, Toff) (Max):
120ns, 70ns
-
-3db Bandwidth:
230MHz
-
Charge Injection:
110pC
-
Channel Capacitance (CS(off), CD(off)):
20pF, 20pF
-
Current - Leakage (IS(off)) (Max):
250pA
-
Crosstalk:
-90dB @ 1MHz
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
10-MSOP
-
Base Part Number:
ADG621
-
detail:
2 Circuit IC Switch 1:1 5.5Ohm 10-MSOP
