دیتاشیت ADP5043ACPZ-1-R7

ADP5043

مشخصات دیتاشیت

نام دیتاشیت ADP5043
حجم فایل 1851.473 کیلوبایت
نوع فایل pdf
تعداد صفحات 30

دانلود دیتاشیت ADP5043

ADP5043 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Topology: Step-down
  • Datasheet: Analog Devices ADP5043ACPZ-1-R7
  • Input Voltage: 1.7V~5.5V
  • Number of Outputs: 2
  • Switching Frequency: 3MHz
  • Operating Temperature: -40°C~+125°C
  • Package: LFCSP-10-EP
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Frequency - Switching: 3MHz
  • Voltage/Current - Output 1: 1.5V, 800mA
  • Voltage/Current - Output 2: 3.3V, 300mA
  • Voltage/Current - Output 3: -
  • w/LED Driver: No
  • w/Supervisor: Yes
  • w/Sequencer: Yes
  • Voltage - Supply: 1.7V ~ 5.5V
  • Mounting Type: Surface Mount
  • Package / Case: 20-WFQFN Exposed Pad, CSP
  • Supplier Device Package: 20-LFCSP-WQ (4x4)
  • Base Part Number: ADP5043
  • detail: PMIC - Voltage Regulators - Linear + Switching 2 Output Step-Down (Buck) (1), Linear (LDO) (1) 3MHz 20-LFCSP-WQ (4x4)
