دیتاشیت ADP3625ARDZ-RL

ADP3623-25,3633-35

مشخصات دیتاشیت

نام دیتاشیت ADP3623-25,3633-35
حجم فایل 316.582 کیلوبایت
نوع فایل pdf
تعداد صفحات 16

دانلود دیتاشیت ADP3623-25,3633-35

ADP3623-25,3633-35 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Driven Configuration: Low-Side
  • Channel Type: Independent
  • Number of Drivers: 2
  • Gate Type: N-Channel MOSFET
  • Voltage - Supply: 4.5V ~ 18V
  • Logic Voltage - VIL, VIH: 0.8V, 2V
  • Current - Peak Output (Source, Sink): 4A, 4A
  • Input Type: Inverting, Non-Inverting
  • Rise / Fall Time (Typ): 10ns, 10ns
  • Operating Temperature: -40°C ~ 150°C (TJ)
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Supplier Device Package: 8-SOIC-EP
  • Base Part Number: ADP3625
  • detail: Low-Side Gate Driver IC Inverting, Non-Inverting 8-SOIC-EP
