ADUM3224WBRZ دیتاشیت

ADUM3224WBRZ

مشخصات دیتاشیت

نام دیتاشیت ADUM3224WBRZ
حجم فایل 102.335 کیلوبایت
نوع فایل pdf
تعداد صفحات 20

مشاهده دیتاشیت ADUM3224WBRZ

دانلود دیتاشیت

سایر مستندات

ADUM3224, 4224 19 pages

مشخصات فنی

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Digital Isolators
  • Data Rate: -
  • Datasheet: Analog Devices ADUM3224WBRZ
  • Applications: -
  • Supply Voltage: 3V~5.5V;4.5V~18V
  • Number of Channels: 2
  • Isolation Technology: Magnetic isolation
  • Operating Temperature: -
  • Voltage Isolation or Not: -
  • Package: SOIC-16
  • Manufacturer: Analog Devices
  • Series: Automotive
  • Packaging: Tube
  • Part Status: Active
  • Technology: Magnetic Coupling
  • Voltage - Isolation: 3000Vrms
  • Common Mode Transient Immunity (Min): 50kV/µs
  • Propagation Delay tpLH / tpHL (Max): 54ns, 54ns
  • Pulse Width Distortion (Max): -
  • Rise / Fall Time (Typ): 12ns, 12ns
  • Current - Output High, Low: -
  • Current - Peak Output: 4A
  • Voltage - Forward (Vf) (Typ): -
  • Voltage - Output Supply: 7.5V ~ 18V
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 16-SOIC
  • Approval Agency: CSA, UR
  • Base Part Number: ADUM3224
  • detail: 4A Gate Driver Magnetic Coupling 3000Vrms 2 Channel 16-SOIC
