ADCMP563BRQZ دیتاشیت

ADCMP563BRQZ

مشخصات دیتاشیت

نام دیتاشیت ADCMP563BRQZ
حجم فایل 98.469 کیلوبایت
نوع فایل pdf
تعداد صفحات 15

مشاهده دیتاشیت ADCMP563BRQZ

دانلود دیتاشیت

سایر مستندات

ADCMP563,564 15 pages

مشخصات فنی

  • RoHS: true
  • Category: Operational Amplifier/Comparator/Comparators
  • Datasheet: Analog Devices ADCMP563BRQZ
  • Package: QSOP-16-150mil
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Obsolete
  • Type: with Latch
  • Number of Elements: 2
  • Output Type: Complementary, Differential, ECL, Open-Emitter
  • Voltage - Supply, Single/Dual (±): ±4.75V ~ 5.25V
  • Voltage - Input Offset (Max): 2mV @ -5.2V,5V
  • Current - Input Bias (Max): 3µA @ -5.2V,5V
  • Current - Output (Typ): 30mA
  • Current - Quiescent (Max): 5mA, 25mA
  • CMRR, PSRR (Typ): 80dB CMRR, 85dB PSRR
  • Propagation Delay (Max): 0.83ns
  • Hysteresis: ±1mV
  • Operating Temperature: -40°C ~ 85°C
  • Package / Case: 16-SSOP (0.154", 3.90mm Width)
  • Mounting Type: Surface Mount
  • Supplier Device Package: 16-QSOP
  • Base Part Number: ADCMP563
  • detail: Comparator with Latch Complementary, Differential, ECL, Open-Emitter 16-QSOP
