ADUM6210BRSZ دیتاشیت

ADUM6210BRSZ

مشخصات دیتاشیت

نام دیتاشیت ADUM6210BRSZ
حجم فایل 100.008 کیلوبایت
نوع فایل pdf
تعداد صفحات 23

دانلود دیتاشیت ADUM6210BRSZ

دانلود دیتاشیت

سایر مستندات

ADuM6210-12 23 pages

مشخصات فنی

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Digital Isolators
  • Datasheet: Analog Devices ADUM6210BRSZ
  • Applications: -
  • Isolation Technology: -
  • Voltage Isolation or Not: -
  • Package: SSOP-20-5.2mm
  • Manufacturer: Analog Devices
  • Series: IsoPower®, iCoupler®
  • Packaging: Tube
  • Part Status: Active
  • Technology: Magnetic Coupling
  • Type: General Purpose
  • Isolated Power: Yes
  • Number of Channels: 2
  • Inputs - Side 1/Side 2: 2/0
  • Channel Type: Unidirectional
  • Voltage - Isolation: 3750Vrms
  • Common Mode Transient Immunity (Min): 25kV/µs
  • Data Rate: 25Mbps
  • Propagation Delay tpLH / tpHL (Max): 35ns, 35ns
  • Pulse Width Distortion (Max): 3ns
  • Rise / Fall Time (Typ): 2.5ns, 2.5ns
  • Voltage - Supply: 2.7V ~ 5.5V
  • Operating Temperature: -40°C ~ 105°C
  • Mounting Type: Surface Mount
  • Package / Case: 20-SSOP (0.209", 5.30mm Width)
  • Supplier Device Package: 20-SSOP
  • Base Part Number: ADUM6210
  • detail: General Purpose Digital Isolator 3750Vrms 2 Channel 25Mbps 25kV/µs CMTI 20-SSOP (0.209", 5.30mm Width)
