دیتاشیت ADP1610ARMZ-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP1610
|
| حجم فایل |
883.192
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
20
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType
-
Topology:
Boost
-
Datasheet:
Analog Devices ADP1610ARMZ-R7
-
Output Type:
Adjustable
-
Input Voltage:
2.5V~5.5V
-
Output Voltage:
2.5V~12V
-
Number of Outputs:
1
-
Switching Frequency:
700kHz;1.23MHz
-
Output Current (Max):
1.2A
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
MSOP-8
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
2.5V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
2.5V
-
Voltage - Output (Max):
12V
-
Current - Output:
1.2A (Switch)
-
Frequency - Switching:
700kHz, 1.23MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
-
Supplier Device Package:
8-MSOP
-
Base Part Number:
ADP1610
-
detail:
Boost Switching Regulator IC Positive Adjustable 2.5V 1 Output 1.2A (Switch) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
