دیتاشیت ADP172ACBZ-2.1-R7
مشخصات دیتاشیت
| نام دیتاشیت | ADP172 Series |
|---|---|
| حجم فایل | 559.857 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت ADP172 Series |
ADP172 Series Datasheet |
|---|
مشخصات
- Manufacturer: Analog Devices Inc.
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Output Configuration: Positive
- Output Type: Fixed
- Number of Regulators: 1
- Voltage - Input (Max): 3.6V
- Voltage - Output (Min/Fixed): 2.1V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.1V @ 300mA
- Current - Output: 300mA
- Current - Quiescent (Iq): 60µA
- Current - Supply (Max): 260nA
- PSRR: 73dB ~ 47dB (1kHz ~ 100kHz)
- Control Features: Enable
- Protection Features: Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
- Operating Temperature: -40°C ~ 125°C
- Mounting Type: Surface Mount
- Package / Case: 4-UFBGA, WLCSP
- Supplier Device Package: 4-WLCSP (0.95x1.03)
- Base Part Number: ADP172
- detail: Linear Voltage Regulator IC 1 Output 300mA 4-WLCSP (0.95x1.03)
