دیتاشیت ADR525BRTZ-REEL7
مشخصات دیتاشیت
| نام دیتاشیت | ADR520,25,30,40,50 |
|---|---|
| حجم فایل | 417.008 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت ADR520,25,30,40,50 |
ADR520,25,30,40,50 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Voltage References
- Datasheet: Analog Devices ADR525BRTZ-REEL7
- Tolerance: ±0.2%
- Output Type: Fixed
- Output Current: 15mA
- Output Voltage: 2.5V
- Reference Type: parallel connection
- Operating Temperature: -40°C~+85°C@(Ta)
- Temperature Coefficient: 40ppm/°C
- Package: SOT-23-3
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Voltage - Output (Min/Fixed): 2.5V
- Current - Output: 15mA
- Noise - 0.1Hz to 10Hz: 18µVp-p
- Noise - 10Hz to 10kHz: -
- Voltage - Input: -
- Current - Supply: -
- Current - Cathode: 50µA
- Mounting Type: Surface Mount
- Package / Case: TO-236-3, SC-59, SOT-23-3
- Supplier Device Package: SOT-23-3
- Base Part Number: ADR525
- detail: Shunt Voltage Reference IC ±0.2% SOT-23-3
