ADL5530ACPZ-R7 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADL5530ACPZ-R7
|
|
حجم فایل
|
67.49
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
16
|
مشخصات فنی
-
Gain:
16dB
-
RoHS:
true
-
Category:
Radio Frequency Chip/Antenna/RF Amplifiers
-
Datasheet:
Analog Devices ADL5530ACPZ-R7
-
Applications:
Cellular,CDMA2000,W-CDMA,GSM
-
Noise Figure:
2.7dB
-
Supply Current:
110mA
-
Supply Voltage:
3V~5V
-
Frequency Range:
0Hz~1GHz
-
Operating Temperature:
-
-
Package:
LFCSP-8
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Frequency:
0Hz ~ 1GHz
-
P1dB:
21.4dBm
-
RF Type:
Cellular, CDMA2000, W-CDMA, GSM
-
Voltage - Supply:
3V ~ 5V
-
Current - Supply:
110mA ~ 135mA
-
Test Frequency:
900MHz
-
Mounting Type:
Surface Mount
-
Package / Case:
8-VFDFN Exposed Pad, CSP
-
Supplier Device Package:
8-LFCSP-VD (3x2)
-
Base Part Number:
ADL5530
-
detail:
RF Amplifier IC Cellular, CDMA2000, W-CDMA, GSM 0Hz ~ 1GHz 8-LFCSP-VD (3x2)
