- دیتاشیت ISO7710(F) Datasheet
ISO7710(F) Datasheet دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ISO7710(F) Datasheet |
|---|---|
| حجم فایل | 1917.672 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت ISO7710(F) Datasheet |
دانلود دیتاشیت |
|---|
سایر مستندات
ISO7710FDR 34 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 100Mbps
- Datasheet: Texas Instruments ISO7710FDWR
- Applications: General-purpose
- Supply Voltage: 2.25V~5.5V
- Forward Channel: 1
- Reverse channel: 0
- Number of Channels: 1
- Isolation Technology: 电容隔离
- Operating Temperature: -55°C~+125°C
- Voltage Isolation or Not: Without voltage isolation
- Package: SOP-16-300mil
- Manufacturer: Texas Instruments
- Type: General Purpose
- Pulse Width Distortion (Max): 4.9ns
- Rise / Fall Time (Typ): 1.8ns, 1.9ns
- Base Part Number: ISO771
- Voltage - Isolation: 5000Vrms
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Voltage - Supply: 2.25V ~ 5.5V
- Supplier Device Package: 16-SOIC
- Common Mode Transient Immunity (Min): 85kV/µs
- Series: -
- Technology: Capacitive Coupling
- Channel Type: Unidirectional
- Propagation Delay tpLH / tpHL (Max): 16ns, 16ns
- Part Status: Active
- Mounting Type: Surface Mount
- Isolated Power: No
- Inputs - Side 1/Side 2: 1/0
- Packaging: Cut Tape (CT)
- detail: General Purpose Digital Isolator 5000Vrms 1 Channel 100Mbps 85kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
