دیتاشیت ADP7102ARDZ-R7

ADP7102

مشخصات دیتاشیت

نام دیتاشیت ADP7102
حجم فایل 1239.218 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت ADP7102

ADP7102 Datasheet

مشخصات

  • Manufacturer: Analog Devices Inc.
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 20V
  • Voltage - Output (Min/Fixed): 1.22V
  • Voltage - Output (Max): 19.675V
  • Voltage Dropout (Max): 0.325V @ 300mA
  • Current - Output: 300mA
  • Current - Quiescent (Iq): 900µA
  • Current - Supply (Max): 1.4mA
  • PSRR: 80dB ~ 50dB (10kHz ~ 100kHz)
  • Control Features: Enable, Power Good, Under Voltage Lockout
  • Protection Features: Over Current, Over Temperature, Reverse Polarity
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width) Exposed Pad
  • Supplier Device Package: 8-SOIC-EP
  • Base Part Number: ADP7102
  • detail: Linear Voltage Regulator IC 1 Output 300mA 8-SOIC-EP
