ADP1650ACPZ-R7 دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
ADP1650ACPZ-R7
|
|
حجم فایل
|
105.076
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
32
|
مشخصات فنی
-
RoHS:
true
-
Type:
DC-DCVoltage Stabilizer
-
Dimming:
I2C
-
Category:
Nixie Tube Driver/LED Driver/LED Drivers
-
Channels:
1
-
Topology:
boost converter
-
Datasheet:
Analog Devices ADP1650ACPZ-R7
-
Input Voltage:
2.7V~5V
-
Output Current:
1.5A
-
Output Voltage:
4.575V~5.5V
-
Switch Frequency:
1.5MHz;3MHz
-
Operating temperature:
-40°C~+85°C
-
Package:
LFCSP-10
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Internal Switch(s):
Yes
-
Number of Outputs:
1
-
Voltage - Supply (Min):
2.7V
-
Voltage - Supply (Max):
5V
-
Voltage - Output:
4.575V ~ 5.5V
-
Current - Output / Channel:
1.5A (Flash)
-
Frequency:
1.5MHz, 3MHz
-
Applications:
Camera Flash
-
Mounting Type:
Surface Mount
-
Package / Case:
10-VFDFN Exposed Pad, CSP
-
Supplier Device Package:
10-LFCSP-WD (3x3)
-
Base Part Number:
ADP1650
-
detail:
LED Driver IC 1 Output DC DC Regulator Step-Up (Boost) I²C Dimming 1.5A (Flash) 10-LFCSP-WD (3x3)
