دیتاشیت ADP5301ACBZ-2-R7

مشخصات دیتاشیت

دانلود دیتاشیت ADP5301 Datasheet	ADP5301 Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices ADP5301ACBZ-2-R7
Input Voltage: 2.15V~6.5V
Output Voltage: 0.8V~5V
Number of Outputs: 1
Switching Frequency: 2MHz
Output Current (Max): 50mA;500mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: WLCSP-9
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Configuration: Positive
Output Type: Programmable
Voltage - Input (Min): 2.15V
Voltage - Input (Max): 6.5V
Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 5V
Current - Output: 50mA, 500mA
Frequency - Switching: 2MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 9-WFBGA, WLCSP
Supplier Device Package: 9-WLCSP (1.87x1.65)
Base Part Number: ADP5301
detail: Buck Switching Regulator IC Positive Programmable 0.8V 1 Output 50mA, 500mA 9-WFBGA, WLCSP
