دیتاشیت REG1118-2.85/2K5

REG1118

مشخصات دیتاشیت

نام دیتاشیت REG1118
حجم فایل 281.404 کیلوبایت
نوع فایل pdf
تعداد صفحات 9

دانلود دیتاشیت REG1118

REG1118 Datasheet

مشخصات

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Texas Instruments REG1118-2.85/2K5
  • Output Current: 800mA
  • Output Voltage: 2.85V
  • Dropout Voltage: 1.3V@(800mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 6V
  • Operating Temperature: 0°C~+70°C
  • Quiescent Current (Ground Current): 7mA
  • Power Supply Rejection Ratio (PSRR): 56dB@(120Hz)
  • Package: SOT-223-4
  • Manufacturer: Texas Instruments
  • Series: -
  • Voltage Dropout (Max): 1.3V @ 800mA
  • Package / Case: TO-261-4, TO-261AA
  • Base Part Number: REG111
  • Supplier Device Package: SOT-223-4
  • Current - Output: 800mA
  • Current - Quiescent (Iq): 7mA
  • Part Status: Active
  • Voltage - Input (Max): 6V
  • Mounting Type: Surface Mount
  • Control Features: -
  • Protection Features: Over Current, Over Temperature
  • Voltage - Output (Min/Fixed): 2.85V
  • PSRR: 56dB (120Hz)
  • Voltage - Output (Max): -
  • Packaging: Tube
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Output Type: Fixed
  • detail: Linear Voltage Regulator IC 1 Output 800mA SOT-223-4
