ADP5003 Datasheet دیتاشیت

ADP5003 Datasheet

مشخصات دیتاشیت

نام دیتاشیت ADP5003 Datasheet
حجم فایل 1030.347 کیلوبایت
نوع فایل pdf
تعداد صفحات 31

مشاهده دیتاشیت ADP5003 Datasheet

دانلود دیتاشیت

سایر مستندات

ADP5003ACPZ-R7 31 pages

ADP5003ACPZ-R7 31 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/DC-DC Converters
  • Topology: Step-down
  • Datasheet: Analog Devices ADP5003ACPZ-R7
  • Input Voltage: 0.65V~5V;4.2V~15V
  • Number of Outputs: 2
  • Switching Frequency: 2.5MHz
  • Operating Temperature: -40°C~+125°C@(TJ)
  • Package: LFCSP-32
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Frequency - Switching: 2.5MHz
  • Voltage/Current - Output 1: 0.6V ~ 5V, 3A
  • Voltage/Current - Output 2: 0.6V ~ 3.3V, 3A
  • Voltage/Current - Output 3: -
  • w/LED Driver: No
  • w/Supervisor: No
  • w/Sequencer: No
  • Voltage - Supply: 0.65V ~ 5V, 4.2V ~ 15V
  • Mounting Type: Surface Mount
  • Package / Case: 32-WFQFN Exposed Pad, CSP
  • Supplier Device Package: 32-LFCSP (5x5)
  • Base Part Number: ADP5003
  • detail: PMIC - Voltage Regulators - Linear + Switching 2 Output Step-Down (Buck) 2.5MHz 32-LFCSP (5x5)
