- دیتاشیت ADP5003ACPZ-R7
ADP5003ACPZ-R7 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADP5003ACPZ-R7 |
|---|---|
| حجم فایل | 110.352 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 31 |
دانلود دیتاشیت ADP5003ACPZ-R7 |
دانلود دیتاشیت |
|---|
سایر مستندات
ADP5003 Datasheet 31 pages
ADP5003ACPZ-R7 31 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Topology: Step-down
- Datasheet: Analog Devices ADP5003ACPZ-R7
- Input Voltage: 0.65V~5V;4.2V~15V
- Number of Outputs: 2
- Switching Frequency: 2.5MHz
- Operating Temperature: -40°C~+125°C@(TJ)
- Package: LFCSP-32
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Frequency - Switching: 2.5MHz
- Voltage/Current - Output 1: 0.6V ~ 5V, 3A
- Voltage/Current - Output 2: 0.6V ~ 3.3V, 3A
- Voltage/Current - Output 3: -
- w/LED Driver: No
- w/Supervisor: No
- w/Sequencer: No
- Voltage - Supply: 0.65V ~ 5V, 4.2V ~ 15V
- Mounting Type: Surface Mount
- Package / Case: 32-WFQFN Exposed Pad, CSP
- Supplier Device Package: 32-LFCSP (5x5)
- Base Part Number: ADP5003
- detail: PMIC - Voltage Regulators - Linear + Switching 2 Output Step-Down (Buck) 2.5MHz 32-LFCSP (5x5)
