دیتاشیت ADF7020BCPZ-RL
مشخصات دیتاشیت
| نام دیتاشیت |
ADF7020
|
| حجم فایل |
1140.209
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
47
|
مشخصات
-
RoHS:
true
-
Category:
Radio Frequency Chip/Antenna/RF Transceiver ICs
-
Datasheet:
Analog Devices ADF7020BCPZ-RL
-
Package:
LFCSP-48-EP(7x7)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Type:
TxRx Only
-
RF Family/Standard:
General ISM < 1GHz
-
Protocol:
-
-
Modulation:
ASK, FSK, GFSK, GMSK, MSK, OOK, O-QPSK
-
Frequency:
431MHz ~ 478MHz, 862MHz ~ 956MHz
-
Data Rate (Max):
200kbps
-
Power - Output:
13dBm (Max)
-
Sensitivity:
-119.2dBm
-
Memory Size:
-
-
Serial Interfaces:
SPI
-
Voltage - Supply:
2.3V ~ 3.6V
-
Current - Receiving:
19mA ~ 21mA
-
Current - Transmitting:
14.8mA ~ 28.5mA
-
Operating Temperature:
-40°C ~ 85°C
-
Mounting Type:
Surface Mount
-
Package / Case:
48-VFQFN Exposed Pad, CSP
-
Supplier Device Package:
48-LFCSP-VQ (7x7)
-
Base Part Number:
ADF7020
-
detail:
IC RF TxRx Only General ISM < 1GHz 431MHz ~ 478MHz, 862MHz ~ 956MHz 48-VFQFN Exposed Pad, CSP
