- دیتاشیت ADuM3151/2/3
ADuM3151/2/3 دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADuM3151/2/3 |
|---|---|
| حجم فایل | 423.986 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت ADuM3151/2/3 |
دانلود دیتاشیت |
|---|
سایر مستندات
ADUM3151BRSZ-RL7 22 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 2Mbps
- Datasheet: Analog Devices ADUM3153ARSZ-RL7
- Applications: SPI
- Supply Voltage: 3V~5.5V
- Forward Channel: 3
- Reverse channel: 4
- Number of Channels: 7
- Isolation Technology: Magnetic isolation
- Operating Temperature: -40°C~+125°C
- Voltage Isolation or Not: Without voltage isolation
- Package: SSOP-20-208mil
- Manufacturer: Analog Devices
- Series: iCoupler®, SPIsolator™
- Packaging: Cut Tape (CT)
- Part Status: Active
- Technology: Magnetic Coupling
- Type: SPI
- Isolated Power: No
- Inputs - Side 1/Side 2: 3/4
- Channel Type: Unidirectional
- Voltage - Isolation: 3750Vrms
- Common Mode Transient Immunity (Min): 25kV/µs
- Propagation Delay tpLH / tpHL (Max): 25ns, 25ns
- Pulse Width Distortion (Max): 3ns
- Rise / Fall Time (Typ): 2.5ns, 2.5ns
- Voltage - Supply: 3V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 20-SSOP (0.209", 5.30mm Width)
- Supplier Device Package: 20-SSOP
- Base Part Number: ADUM3153
- detail: SPI Digital Isolator 3750Vrms 7 Channel 2Mbps 25kV/µs CMTI 20-SSOP (0.209", 5.30mm Width)
