دیتاشیت ADUM1200UR-EP-RL7
مشخصات دیتاشیت
| نام دیتاشیت | ADuM1200-EP |
|---|---|
| حجم فایل | 255.923 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت ADuM1200-EP |
ADuM1200-EP Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 25Mbps
- Applications: General-purpose
- Supply Voltage: 3V~5.5V
- Forward Channel: 2
- Reverse channel: 0
- Number of Channels: 2
- Isolation Technology: Magnetic isolation
- Operating Temperature: -55°C~+125°C
- Voltage Isolation or Not: Without voltage isolation
- Package: SOIC-8
- Manufacturer: Analog Devices
- Series: iCoupler®
- Packaging: Cut Tape (CT)
- Part Status: Active
- Technology: Magnetic Coupling
- Type: General Purpose
- Isolated Power: No
- Inputs - Side 1/Side 2: 2/0
- Channel Type: Unidirectional
- Voltage - Isolation: 2500Vrms
- Common Mode Transient Immunity (Min): 25kV/µs
- Propagation Delay tpLH / tpHL (Max): 45ns, 45ns
- Pulse Width Distortion (Max): 3ns
- Rise / Fall Time (Typ): 2.5ns, 2.5ns
- Voltage - Supply: 3V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: ADUM1200
- detail: General Purpose Digital Isolator 2500Vrms 2 Channel 25Mbps 25kV/µs CMTI 8-SOIC (0.154", 3.90mm Width)
