TPS566235RJNR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
TPS566235RJNR
|
|
حجم فایل
|
95.622
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
29
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Texas Instruments TPS566235RJNR
-
Output Type:
Adjustable
-
Input Voltage:
4.5V~18V
-
Output Voltage:
0.6V~7V
-
Number of Outputs:
1
-
Switching Frequency:
600kHz
-
Output Current (Max):
6A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
Yes
-
Package:
VQFN-13(2x3)
-
Manufacturer:
Texas Instruments
-
Series:
Eco-Mode™
-
Voltage - Input (Min):
4.5V
-
Base Part Number:
TPS566
-
Current - Output:
6A
-
Frequency - Switching:
600kHz
-
Part Status:
Active
-
Voltage - Input (Max):
18V
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
13-VQFN-HR (3x2)
-
Voltage - Output (Min/Fixed):
0.6V
-
Package / Case:
13-VFQFN
-
Voltage - Output (Max):
7V
-
Packaging:
Tape & Reel (TR)
-
Output Configuration:
Positive
-
Synchronous Rectifier:
Yes
-
detail:
Buck Switching Regulator IC Positive Adjustable 0.6V 1 Output 6A 13-VFQFN
