- دیتاشیت ADUM5020-3BRWZ
ADUM5020-3BRWZ دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | ADUM5020-3BRWZ |
|---|---|
| حجم فایل | 99.58 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت ADUM5020-3BRWZ |
دانلود دیتاشیت |
|---|
سایر مستندات
ADuM5020, ADuM5028 20 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: -
- Topology: -
- Datasheet: Analog Devices ADUM5020-3BRWZ
- Input Voltage: 3V~3.6V
- Output Voltage: 3.3V
- Number of Outputs: 1
- Switching Frequency: -
- Output Current (Max): 100mA
- Synchronous Rectification: -
- Package: SOP-16-300mil
- Manufacturer: Analog Devices
- Series: IsoPower®, iCoupler®
- Part Status: Active
- Type: Isolated Module
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 3.6V
- Voltage - Output 1: 3.3V
- Voltage - Output 2: -
- Voltage - Output 3: -
- Voltage - Output 4: -
- Current - Output (Max): 100mA
- Voltage - Isolation: 3kV
- Applications: ITE (Commercial)
- Features: OTP, UVLO
- Operating Temperature: -40°C ~ 125°C
- Efficiency: 33%
- Mounting Type: Surface Mount
- Package / Case: 16-SOIC (0.295", 7.50mm Width)
- Size / Dimension: 0.41" L x 0.30" W x 0.10" H (10.3mm x 7.5mm x 2.7mm)
- Supplier Device Package: 16-SOIC
- Approval Agency: -
- detail: Isolated Module DC DC Converter 1 Output 3.3V 100mA 3V - 3.6V Input
