دیتاشیت ADP5040ACPZ-1-R7
مشخصات دیتاشیت
| نام دیتاشیت |
ADP5040
|
| حجم فایل |
4254.714
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
37
|
مشخصات
-
Manufacturer:
Analog Devices Inc.
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Topology:
Step-Down (Buck) Synchronous (1), Linear (LDO) (2)
-
Number of Outputs:
3
-
Frequency - Switching:
3MHz
-
Voltage/Current - Output 1:
0.8V ~ 3.8V, 1.2A
-
Voltage/Current - Output 2:
0.8V ~ 5.2V, 300mA
-
Voltage/Current - Output 3:
0.8V ~ 5.2V, 300mA
-
w/LED Driver:
No
-
w/Supervisor:
No
-
w/Sequencer:
No
-
Voltage - Supply:
1.7V ~ 5.5V
-
Operating Temperature:
-40°C ~ 125°C
-
Mounting Type:
Surface Mount
-
Package / Case:
20-WFQFN Exposed Pad, CSP
-
Supplier Device Package:
20-LFCSP-WQ (4x4)
-
Base Part Number:
ADP5040
-
detail:
PMIC - Voltage Regulators - Linear + Switching 3 Output Step-Down (Buck) Synchronous (1), Linear (LDO) (2) 3MHz 20-LFCSP-WQ (4x4)
